100HP Tractor
TB1004
Características
High-Torque Power for Heavy Pulling
The TB1004 provides the torque reserve and traction required for heavier agricultural applications. Its 100HP power platform is suited to demanding tillage, towing, transport, and large-implement operations where sustained pulling performance is important.
12F+12R Shuttle Transmission for Better Power Matching
The 12F+12R shuttle transmission provides a broad selection of working speeds while making directional changes easier. The practical speed matching allows operators to keep the engine and implement working conditions better coordinated across different field tasks, helping convert available engine power into productive work.
Independent Controls for Smoother Implement Operation
The independent clutch arrangement makes gear shifting and PTO engagement more convenient when connecting or operating agricultural implements. Full hydraulic steering and side-mounted controls further reduce operating effort, giving the operator more direct control over tractor movement and implement-related tasks.
Practical Details for Longer Working Seasons
The redesigned hood improves access for cleaning and maintenance while promoting engine-compartment ventilation. Enhanced front headlights provide better visibility for early-morning or evening operations, allowing the TB1004 to remain productive when agricultural schedules extend beyond normal daylight hours.
ESPECIFICAÇÕES
| Drive Type | — | 4×4 |
| Rated Power | kW | 74 |
| Overall Dimensions (L × W × H) | mm | 3945 × 1860 × 2730 |
| Wheelbase | mm | 2110 |
| Minimum Ground Clearance | mm | 350 |
| Minimum Operating Mass | kg | 3000 |
| Front Tread | mm | 1400 (1200–1600), Adjustable |
| Rear Tread | mm | 1400 (1300–1600), Adjustable |
| Clutch Type | — | Dry-Type, Double-Acting |
| Engine | — | 4-Cylinder |
| Rated Speed | r/min | 2400 |
| Gear / Transmission | — | 12F + 12R |
| PTO Type | — | Same |
| PTO Rated Power | kW | ≥63 |
| PTO Speed | r/min | 540/720; 540/1000 |
| Three-Point Linkage | — | Rear, 3-Point Suspension, CAT II |
| Hydraulic Output | — | 2-Way Valve |
| Hydraulic Adjustment Mode | — | Same |
| Maximum Lifting Force at 610 mm Frame Center | kN | ≥20.2 |
| Standard Tire Size (Front/Rear) | — | 8.3-24 / 14.9-30 |
| Optional Tire I | — | 9.5-24 / 16.9-30 |
| Optional Tire II | — | 8.3-20 / 12.4-28 |
| Heated Cabin | — | Optional |
| ROPS | — | Optional |
| ROPS with Sunroof | — | Optional |
